A "roller-bearing" or "clevis hanger" pipe support hanger used to support roof-mounted gas pipes, HVAC piping, electrical conduit, solar piping and other mechanical piping. Unique design absorbs thermal expansion and contraction of pipes thus preventing damage to the roof membrane. Pipes rest on a polycarbonate or steel roller hanger or clevis hanger. The pipe support base is made of stainless steel and all other metal parts are hot-dip galvanized. Pipestand will accommodate up to a 16" pipe (inside diameter) or up to 18" (outside diameter) pipes.
- Base Material: Stainless
- Size: Each of the two deck bases are 20" by 20", and has a cradle width which allows a minimum of 24" between the strut assembly.
- Max Pipe Size: 16" inside diameter and 18" outside diameter.
- Max Pipe Clearance: Support pipe from a low of 6 inches to a high of 36 inches in elevation above the roof membrane.
- Max Load Weight: Maximum load weight not to exceed 1,600 lbs. per pipestand or 800 lbs. on each base.
- Spacing: Manufacturer's recommended spacing is not to exceed 10 foot centers depending upon the load. Do not exceed 1,600 lbs. load weight.
Interested in this item or want more information?
Hours:
Phone: (586) 264 - 1962
Email: sales@rsdale.com
Can't find what you want? Give us a call and we can help you find it.
Additional Information
Manufacturer: Miro Industries, Inc.
